CAT 336 and 340

CAT 336 and 340 model excavators include predrilled holes for use with the antenna mast mounts.
Figure: CAT model 336 and 340 antenna mast mounts
  1. Cab
  2. Hood
  3. Counterweight
  4. Upper frame
Related information
Antenna mount locations for tracked excavators
Previous: CAT 325 TEL
Next: CAT 347
